电压输入范围15V~70V, 32dBm~-5dBm的光输入范围最短采样周期300ns。 APD Voltage Input Range :15V to 70V,32dBm~-5dBm Optical Input Range , Sampling Period as Short as 300ns

10Gbps APD跨阻放大器，8kΩ跨阻增益，低频截止频率6kHz，在电源3.3V下功耗90mW。 10Gbps TIA with AGC designed for APD, 8kΩ transimpedance gain, -3dB low frequency cut-off: 6kHz,90mW power consumption under 3.3V power supply.

2.5Gbps APD TIA，灵敏度-34dBm，电源电流24mA，12kΩ跨阻增益。 2.5Gbps APD TIA, -34dBm typical optical sensitivity, 24mA power consumption under 3.3V supply voltage,12kΩ typical transimpedance gain.

1.25Gbps突发模式GPON LA，5mVppd输入灵敏度，可编程LOS/SD指示信号，低噪声，1GHz带宽，48dB增益，5ns突发响应时间 Burst mode limiting amplifier for 1.25Gbps GPON LA,5mVppd input sensitivity, selectable LOS/SD output indicator, low noise, bandwidth of 1GHz, gain of 48dB, 5ns burst response time.

10G PON ONU 对称/非对称光收发一体芯片，平均功率和消光比控制，带有兼容SFF-8472数字诊断监视，LDD最高输出调制/偏置电流为90mA/110mA，LA输入灵敏度为5mVppd，1~12.5Gbps速率，具有连续/突发两种模式。 10Gbps PON ONU symmetrical/asymmetric transceiver,Integrated closed-loop Automatic Power Control (APC)，compliant with SFF8472 digital diagnostics monitoring(DDM)，LDD maximum bias/modulation are 90mA /110mA，LA sensitivity is 5mVppd，1~12.5Gbps Multi-Rate， Switchable burst and continuation mode

1~14Gbps跨阻放大器，典型-17dBm灵敏度，具有良好的速率兼容性和高灵敏度。 Optical TIA with AGC for1~14Gbps, Typical optical sensitivity is -17dBm with good bandwidth compatibility and high sensitivity.

8.5~28 Gbps PIN TIA，在25.78Gbps速率下灵敏度为-14.5dBm，跨阻增益为5.4kΩ，在3.3V电源下功耗为83mW。 25Gbps PIN Transimpedance Amplifier,Typical -14.5dBm sensitivity@25.78Gbps,Data rate from 8.5 to 28Gbps, 5.4kΩ typical differential transimpedance,83mW power consumption under 3.3V power supply.

一款高性能的56Gbaud线性跨阻放大器（ TIA )，设计用于PAM4调制的100Gbps以太网。该器件具有群延迟小、稳定性好、增益高等优点。 High - performance 56Gbaud linear type Transimpedance amplifier ( TIA ), designed for 100Gbps Ethernet operation using PAM4 modulation . The device has been optimized for low group delay variation and good stability with high gain .

四通道28Gbps TIA，-14.5dBm输入灵敏度，信号速率8.5~28Gbps， 5.4kΩ跨阻增益，在3.3Ｖ电源电压下功耗335mW。4 Channel-28Gbps TIA, -14.5dBm optical sensitivity,Data rate from 8.5 to 28Gbps,5.4kΩ typical differential transimpedance, 335mW power consumption under 3.3V power supply.

10G LR Transceiver 最大偏置电流120mA，最大调制电流92mApp，集成自动功率控制环路，可编程 TX眼图调整和输入均衡器，上升下降时间可编程; RX输入灵敏度5mVppd（14Gbps），LOS阈值可调整，RX输出摆幅可编程。 Maximum bias current = 120mA;Maximum modulation current into 15Ω differential TOSA = 92mApp,Integrated closed-loop Automatic Power Control (APC), Programmable TX eye shaping features and input equalization,Programmable rise/fall times，RX sensitivity at14Gbps = 5mVppd,Adjustable loss of signal detect threshold, Programmable RX output swing.

最大偏置电流15mA，最大调制电流20mApp，RX输入灵敏度5mVppd（14Gbps），RX输出预加重和静噪，LOS阈值可调整。 Maximum bias current = 15mA,Maximum modulation current into 50Ω differential TOSA = 20mApp, Laser safety features，Rx sensitivity at 14Gbps = 5mVppd,RX output pre-emphasis and squelch,Adjustable loss of signal detect threshold.

单通道25Gbps DFB激光器驱动;单通道25Gbps 限福放大器;8.5~28.1 Gbps工作速率;0~10dB可编程TX EQ增益；10mVppd的RX输入灵敏度; RXLOS阈值及迟滞可编程。 Single channel 25Gbps DFB Laser Driver;Single channel 25Gbps Limiting Amplifier;8.5~28.1 Gbps operation;programmable TX input EQ gain: 0~10dB;10mVppd RX input sensitivity;programmable RXLOS threshold and hysteresis.

单通道 28Gbps TIA + CDR + LA；-12dBm典型灵敏度（BER=1E-12, ?=0.5A/W, 25.78 Gbps, ER=4 dB），高灵敏度LA，LOS阈值可编程；平均光电流监视；输出摆幅可编程及去预加重功能。 Single channel 28Gbps TIA + CDR + LA;　-12dBm typical sensitivity: BER=1E-12, ?=0.5A/W, 25.78 Gbps, ER=4 dB; High-sensitivity limiting amplifier with programmable LOS threshold; Average Photodiodecurrent monitor; Programmable output swing and de-emphasis.

8.5 ~28 Gbps APD TIA，在高速模式下的等效输入噪声为1.05uA，信号速率8.5~28Gbps，跨阻增益为5.4kΩ，在3.3V电源电压下功耗为83mW。 28Gbps APD Transimpedance Amplifier,Typical 1.05uA noise in high rate mode,Data rate from 8.5 to 28Gbps,5.4kΩ typical differential transimpedance, 83mW power consumption under 3.3V power supply.

8.5~28 Gbps PIN TIA，在25.78Gbps速率下灵敏度为-14.5dBm，跨阻增益为5.4kΩ，在3.3V电源下功耗为83mW。 25Gbps PIN Transimpedance Amplifier,Typical -14.5dBm sensitivity@25.78Gbps,Data rate from 8.5 to 28Gbps, 5.4kΩ typical differential transimpedance,83mW power consumption under 3.3V power supply.

八 位 8 0 5 1 内 核 MCU,72MHz 最 高 工 作 频 率 ( 精 度 ± 2 % ) , 9 0 0ksps +四 位 2 0 通 道 ADC, 片内温度传感器(精度 ± 3 % ) , 六 通 道 PWM/PCA。 提 供QFN32/QFN24 封 装 。 Pipelined 8-bit 8051 MCU Core with maximum 72 MHz 14-bit 20 channels ADC,Internal calibrated temperature QFN32/QFN24 package.

10G PON ONU 对称/非对称光收发一体芯片，平均功率和消光比控制，带有兼容SFF-8472数字诊断监视，LDD最高输出调制/偏置电流为90mA/110mA，LA输入灵敏度为5mVppd，1~12.5Gbps速率，具有连续/突发两种模式。 10Gbps PON ONU symmetrical/asymmetric transceiver,Integrated closed-loop Automatic Power Control (APC)，compliant with SFF8472 digital diagnostics monitoring(DDM)，LDD maximum bias/modulation are 90mA /110mA，LA sensitivity is 5mVppd，1~12.5Gbps Multi-Rate， Switchable burst and continuation mode

0G LR Transceiver 最大偏置电流120mA，最大调制电流92mApp，集成自动功率控制环路，可编程 TX眼图调整和输入均衡器，上升下降时间可编程; RX输入灵敏度5mVppd（14Gbps），LOS阈值可调整，RX输出摆幅可编程。 Maximum bias current = 120mA;Maximum modulation current into 15Ω differential TOSA = 92mApp,Integrated closed-loop Automatic Power Control (APC), Programmable TX eye shaping features and input equalization,Programmable rise/fall times，RX sensitivity at14Gbps = 5mVppd,Adjustable loss of signal detect threshold, Programmable RX output swing.

3.5W QSFP28 模块总消散功耗，便捷的发射眼图调整，缩短设计时间。 3.5W total QSFP28 module power dissipation.100G TOSA leverages simple manufacturing flow, electronic Laser eye tuning reduces design time.

一款宽频带、快速过载恢复、强转换速率、超低噪声和超低谐波失真跨阻放大器，用于光电二极管监控应用。多反馈电阻，简化了高性能光学系统的设计。适用于OTDR系统。 A wideband, fast overdrive recovery, strong slew rate, ultralow-noise and ultralow-HD transimpedance amplifier targeted at photodiode monitoring applications. Multiple-feedback resistance, the EOC1202 simplifies the design of high-performance optical systems which is fit for OTDR system.

3.5W QSFP28 模块总消散功耗，便捷的发射眼图调整，缩短设计时间。 3.5W total QSFP28 module power dissipation.100G TOSA leverages simple manufacturing flow, electronic Laser eye tuning reduces design time.

单通道25Gbps VCSEL激光器驱动;单通道25Gbps 限福放大器;8.5~28.1 Gbps工作速率;0~10dB可编程TX EQ增益；10mVppd的RX输入灵敏度; RXLOS阈值及迟滞可编程。 Single channel 25Gbps VCSEL Laser Driver;Single channel 25Gbps Limiting Amplifier;8.5~28.1 Gbps operation;programmable TX input EQ gain: 0~10dB;10mVppd RX input sensitivity;programmable RXLOS threshold and hysteresis.

四通道28Gbps TIA + CDR + LA；-12dBm典型灵敏度，LOS阈值可编程；平均光电流监视；输出摆幅可编程及去加重功能。 4 Channel 28Gbps TIA + CDR + LA; -12dBm typical sensitivity.High-sensitivity limiting amplifier with programmable LOS threshold.Average photodiode current monitor, Programmable output swing and de-emphasis.

单通道 25Gbps TIA + CDR + LA；-12dBm典型灵敏度（BER=1E-12, ?=0.5A/W, 25.78 Gbps, ER=4 dB），高灵敏度LA，LOS阈值可编程；平均光电流监视；输出摆幅可编程及去预加重功能。 Single channel 28Gbps TIA + CDR + LA;　-12dBm typical sensitivity: BER=1E-12, ?=0.5A/W, 25.78 Gbps, ER=4 dB; High-sensitivity limiting amplifier with programmable LOS threshold; Average Photodiodecurrent monitor; Programmable output swing and de-emphasis.

25G LR Transceiver 通道25Gbps DFB激光器驱动;单通道25Gbps 限福放大器;8.5~28.1 Gbps工作速率;0~10dB可编程TX EQ增益；10mVppd的RX输入灵敏度; RXLOS阈值及迟滞可编程。 Single channel 25Gbps DFB Laser Driver;Single channel 25Gbps Limiting Amplifier;8.5~28.1 Gbps operation;programmable TX input EQ gain: 0~10dB;10mVppd RX input sensitivity;programmable RXLOS threshold and hysteresis.

一 款输出60V, 内 置 1 . 0A、 内阻0 .6Ω开关的升压转换器，670KHz 开关频率，具有快速电流保护、欠压锁定和过压保护、热保护等功能。可用于激光雷达发射及接收高压电路 Monolithic step up converter integrating a 1.0A,0.6Ω internal switch.Current mode,fixed frequency archi-tecture,providing fast transient response and cycle by cycle current limit.Includes under-voltage lockout,over voltage protection and thermal overload protection.Includes under-voltage lockout,over voltage protection and thermal overload protection preventing damagein the event of an output overload .

4.5ms传输超时;轨对轨输入输出;80MHz最高开关频率;3.2mA静态2.7V至5.5V的电源电压;. 4.5ms Propagation Delay;Rail-to-Rail Input and Output;Maximum trogle frequency:80MHz;3.2mA Supply Current;Supply Voltage:2.7V to 5.5V;

是 一 款 4 通 道 5V 高增益、过载快恢复、高带宽、低噪声、低失真、低功耗跨导放大，具有较宽输入动态范 围和高输出摆幅。适用于激光雷达包含汽车类激光雷达等高性能要求光学系统设计要求。 Gain:74kQ/Bandwidth@maximum 2pF:220MHz/Input Current Noise@200MHz,2pF:58nARMS Linear Input Range:Ou A to-30μA/Output Swing:2VP-P/Power consumption:230mW

是 一 款 单 通 道 5V 高增益、过载快恢复、高带宽、低噪声、低失真、低功耗跨导放大。具有较宽输入动态范围和高输出摆幅。适用于激光雷达包含汽车类激光雷达等高性能要求光学系统设计要求。 Gain:74kΩ/Bandwidth@maximum 2pF:220MHz/Input Current Noise@200MHz,2pF:58nARMS Linear Input Range:OuA to-30μA /Power consumption:95mW

是一款宽带、快速恢复、高摆率、具有超低噪声和超低失真的跨导放大器 (TIA) 。 多种反馈电阻选择，适用于激光雷达等高性能要求光学系统设计要求。 EOC1070Q is a wideband,fast overdrive recovery,strong slew rate,ultralow-noise and ultralow-HD tran-simpedance amplifier.Multiple feedback resistance options for high performance requirements such as LiDAR optical system design requiremen
